The Honeytek HK60D 2,000 counts handheld insulation tester is a 1000V handheld insulation tester developed for buyers who need higher resistance coverage than basic models. Compared with standard entry-level units, this model extends measurement up to 2000MΩ, making it more suitable for broader industrial maintenance and electrical testing applications.
Key Features
1000V insulation testing
Extended insulation resistance measurement up to 2000MΩ
2,000-count digital display
Manual range selection
Low battery display
Auto power off
CAT III 1000V safety design
Portable and lightweight structure
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Honeytek HK60D 2,000 counts handheld insulation tester |
| Display Count | 3 1/2 digit (2000 counts) |
| Test Voltage Accuracy | 1000V ±10% |
| Range Selection | Manual |
| Low Battery Display | Yes |
| Auto Power Off | Yes |
| Operating Temperature | 0°C to 40°C (RH ≤85%) |
| Storage Temperature | -10°C to 50°C (RH ≤75%) |
| CAT Rating | CAT III 1000V |
| Battery Type | 6F22 9V |
| Accessories | High-voltage insulation test leads ×1, 6F22 9V battery ×1, instruction manual, carrying case |
| Display Size | 61 × 37 mm |
| Product Size | 190 × 88.5 × 27.5 mm |
| Product Weight | 427 g |
| CTN Size | 50 × 31 × 46 cm |
| Qty/CTN | 30 pcs |
| NW/GW | 21 kg / 22 kg |
Insulation Resistance Accuracy
| Test Voltage | Range | Accuracy |
|---|---|---|
| 1000V | 1MΩ–200MΩ | ±(3% + 3d) |
| 1000V | 200MΩ–1000MΩ | ±(4% + 2d) |
| 1000V | 1000MΩ–2000MΩ | ±(5% + 5d) |
Applications
Insulation testing in industrial motors, cables, and switchgear
Maintenance work in power distribution systems
Suitable for electrical contractors and industrial service teams
Higher-range 1000V model for professional resale channels
FAQ
Q1: What is the difference between the Honeytek HK60C 2,000 counts handheld insulation tester and the Honeytek HK60D 2,000 counts handheld insulation tester?
The HK60D extends insulation resistance measurement up to 2000MΩ, while the A60C is positioned as a simpler 1000V / 200MΩ model.
Q2: Is the HK60D suitable for industrial buyers?
Yes. It is better suited for industrial buyers who need a 1000V tester with wider measurement coverage.
Q3: Is this model portable?
Yes. It has a compact handheld format and weighs 427 g.
Q4: Is it a good product for distributors?
Yes. It fits well into a product line targeting professional users, contractors, and maintenance teams.
