Honeytek HK788A 6000 Counts TRMS Clamp Meter
Product Description:
The Honeytek HK788A is a versatile and reliable True RMS digital clamp meter designed for professional electricians and technicians. With a high 6000-count display, it ensures accurate readings even in fluctuating electrical environments. It offers a comprehensive suite of measurement functions, including AC/DC voltage, AC current, resistance, capacitance, frequency, duty cycle, and temperature. Safety is paramount, with a CAT III 600V rating, making it suitable for a wide range of electrical troubleshooting tasks in residential, commercial, and light industrial settings. Features like Non-Contact Voltage (NCV) detection, a built-in flashlight, and data hold make it a practical and efficient tool for daily use.
Key Highlights:
True RMS Accuracy: Provides accurate measurements of non-linear signals.
NCV Detection: Allows for quick and safe detection of energized wires.
Multi-Function Tool: Measures voltage, AC current, resistance, capacitance, frequency, duty cycle, and temperature.
Enhanced Safety: Rated CAT III 600V.
User-Friendly Design: Includes a flashlight, LCD backlight, data hold, and auto power-off.
Applications:
General electrical installation, HVAC system troubleshooting, appliance repair, and industrial control system diagnostics.
Specifications
| Function | Range | Accuracy |
|---|---|---|
| DC Voltage (V) | 600mV, 6V, 60V, 600V, 1000V | ±(0.5%+3d) for 600mV ±(0.7%+3d) for other ranges |
| AC Voltage (V) | 6V, 60V, 600V, 1000V | ±(1.0%+5d) for 6V/60V/600V ±(1.0%+10d) for 1000V |
| AC Current (A) | 6A, 60A, 600A | ±(2.5%+5d) |
| Resistance (Ω) | 600Ω, 6kΩ, 60kΩ, 600kΩ, 6MΩ, 60MΩ | ±(1.0%+2d) for 600Ω ±(0.8%+2d) for 6k-6MΩ ±(2.5%+5d) for 60MΩ |
| Capacitance (F) | 10nF, 100nF, 1µF, 10µF, 100µF, 1mF, 10mF, 100mF | ±(3.0%+5d) for 10nF-100µF ±(10%+5d) for 1mF-100mF |
| Frequency (Hz) | 10Hz, 100Hz, 1kHz, 10kHz, 100kHz, 1MHz, 10MHz | ±(0.5%+2d) |
| Temperature (°C) | -40°C to 0°C, 0°C to 400°C, 400°C to 1000°C | ±4d, ±(2.0%+3d), ±(3.0%+3d) |
| Temperature (°F) | -40°F to 32°F, 32°F to 752°F, 752°F to 1832°F | ±6d, ±(2.0%+5d), ±(3.0%+5d) |
| Duty Cycle | 0.1% to 99.9% |
| General Feature | Specification |
|---|---|
| Display | 5999 Counts, LCD with Backlight |
| Safety Rating | CAT III 600V |
| Special Functions | Diode Test, Continuity Buzzer, NCV, Live Wire, LoZ, Flashlight, Data Hold, MAX/MIN, Relative Mode, Auto Power Off |
| Jaw Size | Φ30.5×44.5mm (30mm opening) |
| Power Supply | 2 x 1.5V AA Batteries |
| Product Dimensions | 230 x 85 x 40 mm |
| Product Weight | 250g |
