The Honeytek A60E 2,000 counts handheld insulation tester is a compact 500V insulation tester intended for buyers seeking a practical basic model for everyday insulation checks. For wholesalers, distributors, and importers, it works well as an entry-level 500V option for electrical maintenance, installation testing, and resale in general electrical markets.
The Honeytek A60E 2,000 counts handheld insulation tester measures insulation resistance from 0.01MΩ to 200MΩ at 500V, making it suitable for common low- to mid-voltage insulation testing tasks. Its simple design helps channel partners offer a dependable model without overcomplicating the product line.
Key Features
Single test voltage: 500V
Measures insulation resistance from 0.01MΩ to 200MΩ
2,000-count digital display
Manual range selection
Low battery display
Auto power off
CAT III 1000V safety rating
Lightweight handheld format
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Honeytek A60E 2,000 counts handheld insulation tester |
| Display Count | 3 1/2 digit (2000 counts) |
| Test Voltage Accuracy | 500V ±10% |
| Insulation Resistance Range | 0.01MΩ–200MΩ |
| Accuracy | ±(3% + 3d) |
| Range Selection | Manual |
| Low Battery Display | Yes |
| Auto Power Off | Yes |
| Operating Temperature | 0°C to 40°C (RH ≤85%) |
| Storage Temperature | -10°C to 50°C (RH ≤75%) |
| CAT Rating | CAT III 1000V |
| Battery Type | 6F22 9V |
| Accessories | High-voltage insulation test leads ×1, 6F22 9V battery ×1, instruction manual, carrying case |
| Display Size | 61 × 37 mm |
| Product Size | 190 × 88.5 × 27.5 mm |
| Product Weight | 427 g |
| CTN Size | 50 × 31 × 46 cm |
| Qty/CTN | 30 pcs |
| NW/GW | 21 kg / 22 kg |
Applications
General insulation checks in building wiring and electrical maintenance
Entry-level 500V testing for installers and service technicians
Good channel product for resellers and distributors
Suitable for markets that prefer simple and affordable insulation testers
FAQ
Q1: What voltage does the Honeytek A60E 2,000 counts handheld insulation tester use?
It is a 500V insulation tester.
Q2: What range does it measure?
It measures insulation resistance from 0.01MΩ to 200MΩ.
Q3: Is this model suitable for large industrial projects?
It is better suited for general-purpose and entry-level 500V insulation testing, rather than higher-range applications.
Q4: Why do distributors choose models like this?
Because it is easy to position, simple to explain, and attractive for customers seeking a basic handheld insulation tester.
